Fixing Dolfinx-external-operator: The Operand Overwrite Bug

Hey folks! Today, we're diving deep into a crucial bug that can trip up your advanced simulations when using dolfinx-external-operator. Specifically, we're talking about an issue where the evaluate_operands function, which is supposed to handle our external operator inputs, overwrites previously evaluated operands when an FEMExternalOperator has multiple operands that might share UFL expressions. This isn't just a minor glitch; it can lead to entirely incorrect simulation results, making your perfectly crafted models behave unpredictably. Understanding this FEMExternalOperator bug is paramount for anyone doing serious finite element analysis with dolfinx and its powerful extensions, especially when dealing with complex material models or coupled physics problems. We’ll break down exactly what’s happening, why it’s a problem, and what you need to look out for. So, buckle up, because getting this right means more accurate, robust simulations for all of us!

This particular evaluate_operands overwriting bug has been observed in dolfinx v0.9.0 and dolfinx-external-operator of the same version, and the core code responsible for this behavior remains unchanged in v0.10.0. This means that if you're working with these versions, you're potentially exposed to this issue. The impact of such a bug can be profound. Imagine you’re trying to model a hyperelastic material where the stress response depends on several invariants, and perhaps some scalar material parameters. If one of these critical operands is incorrectly evaluated or overwritten during the assembly of your residual or Jacobian, your Newton solver might fail to converge, or worse, converge to a physically meaningless solution. We're talking about lost simulation time, wasted computational resources, and ultimately, unreliable scientific conclusions. Therefore, a thorough understanding of this FEMExternalOperator bug is not just good practice, it's absolutely essential for ensuring the integrity of your numerical experiments. We'll explore how this happens in detail, including the specific code path that leads to the overwrite, and provide a minimal code example to demonstrate the problem, making it crystal clear for everyone involved in dolfinx development or application. Our goal here is to empower you with the knowledge to either detect and mitigate this issue or contribute to a permanent fix, fostering a more robust dolfinx ecosystem for everyone.

Diving Deep: The evaluate_operands Bug Explained

Alright, let’s get down to the nitty-gritty of this evaluate_operands bug. The core of the issue lies within how dolfinx-external-operator handles the evaluation of inputs when an FEMExternalOperator is constructed with multiple operands, especially when these operands might, under certain circumstances, refer to the same underlying UFL expression or become effectively identical in the evaluation dictionary. Picture this: you've defined a fancy FEMExternalOperator that takes two inputs – say, an invariant like I1_bar (the first invariant of the isochoric right Cauchy-Green deformation tensor, a common player in hyperelasticity) and a simple scalar material parameter like slope. The idea is that your external function, let's call it dPsi_dI1, needs both of these values at each quadrature point to correctly compute its output. You build your residual and Jacobian forms, then wrap your nonlinear solver callbacks to ensure these external operators are updated at every Newton iteration. During the Jacobian/Residual assembly, evaluate_operands is called to compute these input values, and then evaluate_external_operators uses those results to get the final operator outputs. Sounds straightforward, right? Well, here’s where the FEMExternalOperator bug sneakily appears, causing a major headache for accurate simulations.

The problematic scenario emerges because both external operators, when expanded for the Jacobian, can end up sharing the same UFL operands list. This isn't necessarily a bug in itself, but it becomes problematic due to the dictionary logic within evaluate_operands. The function tries to be smart: it iterates over all these operands and stores their evaluated values in a dictionary, using the operand expression itself as the key. This KeyError check, while seemingly innocuous, is where things go south. For the first external operator, let’s say it needs operand A and operand B. evaluate_operands correctly computes A and stores it. Then it computes B and stores it. All good so far. Now, imagine a second external operator that also needs operand A (maybe it’s a derivative of the first, and A is still a relevant input). When evaluate_operands processes this second operator, it encounters operand A again. Because A is already a key in the evaluated_operands dictionary, the try: evaluated_operands[operand] block does not raise a KeyError. This means the code path immediately proceeds to evaluated_operands[operand] = evaluated_operand, overwriting the correctly evaluated value of A from the first pass with what essentially amounts to the last evaluated operand from the previous external operator's context. In simpler terms, the dictionary entry isn't being reused correctly; it's being reset with potentially wrong data, specifically the value of the last operand evaluated, regardless of which operator it actually belonged to or if its value was already correctly computed and stored. This silent overwriting of critical data means that subsequent computations that rely on operand A will be using a completely bogus value, leading to erroneous Jacobian or residual assemblies. This is a classic example of an unintended side effect that can wreak havoc in numerical methods, especially when the robustness of Newton solvers depends so heavily on accurate derivative information. The implication is profound: your material response might be computed using the wrong physical inputs, leading to non-physical stress states, inaccurate deformations, and ultimately, unreliable simulation outcomes. This FEMExternalOperator issue underscores the importance of rigorous testing and understanding the internal mechanisms of numerical libraries, particularly when dealing with complex symbolic differentiation and evaluation frameworks.

Symptoms in Action: What You'll See

When this evaluate_operands bug kicks in, the symptoms can be quite alarming, and they make debugging incredibly tricky without a deep dive into the library's internals. The most telling sign, as observed during debugging, is that if you print the evaluated operands during Jacobian assembly (or residual assembly, for that matter), you'll find that all evaluated values turn out to be equal to the scalar parameter. Let’s say our invariant I1_bar should be varying across the mesh, while our slope parameter is a constant. You’d expect I1_bar to have a range of values and slope to be uniform. But instead, you see I1_bar also reporting the constant value of slope at every single quadrature point! This is a clear red flag that something is fundamentally wrong with the operand evaluation, directly indicating the FEMExternalOperator bug. The first operand, which should represent the invariant and have spatially varying values, is incorrectly overwritten by the value of the second, scalar operand. This isn't just a minor numerical error; it's a complete corruption of input data for your external operator.

These incorrectly evaluated operands have immediate and severe downstream consequences. Firstly, your FEMExternalOperator will compute its output based on these wrong inputs, leading to an inaccurate Piola stress (or whatever constitutive model you are implementing). This directly affects the residual form, causing the system of equations to be assembled incorrectly. But it gets worse: the Jacobian form, which is the derivative of the residual with respect to the solution variable, will also be built using these faulty operand evaluations. A corrupted Jacobian is a death sentence for Newton’s method. Newton solvers rely on accurate Jacobian matrices to compute the search direction for the next iteration. If the Jacobian is wrong, the solver will likely fail to converge, leading to messages about PETSc non-convergence or an extremely slow, erratic convergence that eventually stalls. Even if it does converge, it might converge to an incorrect local minimum or a physically meaningless solution, because the underlying system it's solving is fundamentally flawed. This means your simulation results—the deformations, stresses, and forces—will be inaccurate, misleading, and ultimately unreliable. For engineers and scientists, this means that the outputs of their simulations, which are often used for critical design decisions or scientific discovery, cannot be trusted. The evaluate_operands overwrite effectively renders the FEMExternalOperator useless for scenarios involving multiple, potentially shared operands, undermining the very purpose of this powerful extension to dolfinx. The insidious nature of this bug is that it might not always immediately manifest as a crash; it could silently produce wrong results, making it even more dangerous. This highlights the crucial need for developers to be aware of such low-level interactions and for users to rigorously validate their models, especially when integrating advanced features like external operators in complex nonlinear simulations. Without a clear understanding of the FEMExternalOperator bug and its manifestation, you could be spending countless hours troubleshooting what appears to be a model issue, when in reality, it's a fundamental problem in the numerical machinery. The ability to correctly diagnose and address this evaluate_operands problem is a hallmark of robust simulation practice.

Deconstructing the Code: A Minimal Example Walkthrough

Let's pull back the curtain and walk through the minimal code example provided to truly understand where this evaluate_operands bug lives. This example is crafted to demonstrate the FEMExternalOperator problem in its simplest form, showcasing how the erroneous operand overwriting occurs during a standard dolfinx nonlinear solve process. By dissecting each part, we can pinpoint the exact mechanisms at play.

Setting Up the Simulation: Mesh, Spaces, and Kinematics

First off, like any good dolfinx simulation, we start by setting up our computational domain. We create a simple 2D rectangle mesh using mesh.create_rectangle, spanning from [0.0, 0.0] to [1.0, 1.0] with 4x4 elements. This provides a basic canvas for our problem. Next, we define our function spaces. We need a space for our primary displacement variable, u. For this, `V = fem.functionspace(domain, (
